Brand: Tonhi
Model: Sox-e 91w By22d
| Quantity: | |
|---|---|
TH-SOX-E 91W
TONHI
| Product name | SOX 35W BY22d | SOX 55W BY22d | SOX 90W BY22d | SOX 135W BY22d |
| D(Max) | 53mm | 53mm | 66mm | 66mm |
| C(Max) | 311mm | 425mm | 525mm | 765mm |
| Energy Consumption kWh/1000h | 40kWh | 61kWh | 100kWh | 148kWh |
| Energy Efficiency Label(EFL) | A+ | A++ | A++ | A++ |
| Lamp Current (Nom) | 0.53 A | 0.51 A | 0.82 A | 0.82 A |
| Voltage (Nom) | 70 V | 109 V | 112 V | 164 V |
| Power (Rated) (Nom) | 37 W/(±3W) | 56.0 W (±3W) | 91.0(±3 W) | 135.0(±3 W) |
| Operating Position | H110 | H110 | P20 | P20 |
| Lumen Maintenance 2000h (Nom) | 95% | 98% | 95% | 95% |
| Lumen Maintenance | 90% | 90% | 90% | 90% |
| 5000 h (Nom) | ||||
| Luminous Efficacy | 129 lm/W | 140 lm/W | 150 lm/W | 167 lm/W |
| (rated) (Nom) | ||||
| Luminous Flux (Nom) | 4500 lm | 7800 lm | 13600 lm | 22600 lm |
| Bulb Shape | T53 | T53 | T66 | T66 |
If you want to know more, please contact me. I'm Claire
Q1. Can I have a sample order ?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time ?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for large order quantity.
Q3. How to proceed an order ?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q4. Is it OK to print my logo ?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q5: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
