| Name | 1000w HPS Double Ended Grow Lights |
| Color Temperature(CCT) | 2100K |
| Reflector | 95% Germany Alanord Reflector |
| Lamp Luminous Efficiency(lm/w) | 155 |
| Application | GreenHouse/Indoor Plant/ |
| Warranty | 3 Years |
| Brand | TONHI |
| Quantity: | |
|---|---|
TH-1000W DE
specifications
Performance Data:
Initial Lumens (Lumens 100hours) 15500
Efficiency (Lm/W) 155
Photon flux (μmol/s) 2000
Rated Life (Hours) 10000
Correlated Colour Temperature (K) 2100
Chromaticity (CIE-X, Y) x-0.520 y-0.540
Colour Rendering Index (CRI) 22
Typical Warm-up Time (Minutes) 3~5
Physical Date / Requirements:
Base Designation K12*30s
Bulb Designation T32
Bulb Diameter (mm) 32.5
Max. Overall Length (MOL) (mm) 410
Light Centre Length (LCL) (mm) ---
Max.Base Temperature (℃) 250
Max.Bulb Temperature (℃) 700
Luminaire Type Enclosed
Electrical Data / Requirements:
Lamp Wattage (W) 1000
Operating Voltage (V) 215
Operating Current (Amps) 4.7
Min.Open Circuit Voltage (RMS) 456
Min. -Max.Staring Pulse (Peak kV) 4~5
Min. Pulse Width 2700Volts (μ sec) 2
Min.Pulse Rate Per 1/2 Cycle 1
Pulse Position (Min. % OCV Peak) 60~90 240~270
specifications
Performance Data:
Initial Lumens (Lumens 100hours) 15500
Efficiency (Lm/W) 155
Photon flux (μmol/s) 2000
Rated Life (Hours) 10000
Correlated Colour Temperature (K) 2100
Chromaticity (CIE-X, Y) x-0.520 y-0.540
Colour Rendering Index (CRI) 22
Typical Warm-up Time (Minutes) 3~5
Physical Date / Requirements:
Base Designation K12*30s
Bulb Designation T32
Bulb Diameter (mm) 32.5
Max. Overall Length (MOL) (mm) 410
Light Centre Length (LCL) (mm) ---
Max.Base Temperature (℃) 250
Max.Bulb Temperature (℃) 700
Luminaire Type Enclosed
Electrical Data / Requirements:
Lamp Wattage (W) 1000
Operating Voltage (V) 215
Operating Current (Amps) 4.7
Min.Open Circuit Voltage (RMS) 456
Min. -Max.Staring Pulse (Peak kV) 4~5
Min. Pulse Width 2700Volts (μ sec) 2
Min.Pulse Rate Per 1/2 Cycle 1
Pulse Position (Min. % OCV Peak) 60~90 240~270
